Raritan
SKU/Product #: CPRKII

Compact II Kit

$0.00

Product Description

This Kit is No Longer Available, As The Raritan Compact Model is Discontinued.

This rebuild kit has been replaced by the Retrofit Kit to the current PHII Pump.





THIS KIT IS NOT AVAILABLE. The below information is ONLY for refrence:

Compact II Kit

Includes:
Item #: 1214B -O-ring
Item #: 1226C -Plastic Spacer Washers (4)
Item #: 1228CW -Flapper Valve Assembly
Item #: 1234 -Bowl Gasket, white
Item #: 1316MS -Piston O-ring
Item #: 1350W -Check Valve Assembly
Item #: 1353 -Piston Rod Bumper Washer (2)
Item #: 1356 -Seal Cartridge
Item #: 1357 -U-cup Seal (2)
Item #: C253 -Joker Vkave
Item #: RNI -Nylon Shoulder Washer (4)
Item #: SL1CC -Super Libe iCC packets (2)


Warning: This item may contain ingredients that are listed under P65warnings.ca.gov
