Raritan
SKU/Product #: PHRKIIU

Universal PH Rebuild Kit

$75.00
$105.00
Shipping: Calculated at Checkout

Product Description

Universal Repair Kit for PH, P100/P200 & Fresh Head

Includes: (see image below for parts directory)

  • 1201: Inlet and outlet Valve Ball (2)
  • 1202: Inlet & Outlet Valve Cap Gasket -White (2)
  • 1203B1: Inlet Valve Stem O-ring (small black)
  • 1203B2: Inlet Valve Body O-ring (medium black) (2)
  • 1203B3: Inlet Valve Bottom O-ring (large black)
  • • 1213A -Pre 1992: "U" Cup (install flat side up)
    • 1213B -Pre 1992: Derlin Washer (stiff plastic)
    • 1213C -Pre 1992: Snap Ring (curved side down)
    • 1213D -Pre 1992: White Rubber Washer (slides loose on piston rod)
  • 1214: Seal Cartridge
  • 1214A: Piston Shaft Seal (install with flat side up)
  • 1214B: O-ring (large black thin cross section)
  • 1226C: Housing Spacer Washer (for 1228CWflapper valve) (4)
  • 1228CW: Flapper Valve Assembly (install with weight up, flat side towards bowl)
  • 1232MS: Piston Multiseal O-ring
  • 1234: Bowl Gasket (white rubber)
  • 25103: Base O'Ring
  • 25104: Base Mounting Hole Plug (4)
  • 25105: Bowl Gasket O-Ring
  • C253: Joker Valve (duckbill faces away from toilet)
  • RNI: Nylon Shoulder Washer (replaces #1240 rubber grommet) (4)
  • Super Lube 1CC packet (3)
