Tecma Silence RV Flush Panel, 2-button

FUNCTIONS:

Caution- To avoid damage to unit, flush only organic
material and toilet paper.

• ADD WATER button – Initiates water inlet to fill the toilet with a small amount of water.

Warning- To avoid possible overflows the “ADD WATER”
button will only allow inlet water two times
before requiring a mandatory flush using the
“FLUSH” button.

• FLUSH button – Initiates the macerator pump to run and to empty the bowl.

WATER LEVEL PROGRAMMING:

The water amount used during every flush cycle can be adjusted directly on the wall switch.

• Remove wall switch from the wall
• Rotate dial on the rear of the wall switch to the right to increase the amount of water and to the left to decrease the amount of water

Notice- The recommended water level is at least 1cm above the ceramic bowl.

ADD WATER:

Press and release left button. Recommended for flushing solids
and toilet paper.

FLUSH:

Press and release right button. Recommended for flushing liquids and small amounts of toilet paper only.

Pump Manual Activation (Empty Bowl):

Press both buttons simultaneously for 4 seconds and release. This empties the bowl and leaves it dry for travel. Press the ADD
WATER button to resume normal use.

Caution- Refill the toilet as soon as possible after emptying the bowl. Leaving water out of the plumbing trap can result in objectionable odors.
